質問 # 34
You want to ensure thatVXLAN traffic from the xe-0/0/12 interlace is being encapsulatedby logical vlep.
32770 and sent to a remote leaf device in this scenario, which command would you use to verify that traffic is flowing?
- A. monitor traffic interface xe-0/0/12
- B. show interfaces terse vtep.32770 statistics
- C. show interface terse vtep.32770
- D. show interfaces vtep.32770 detail
正解：B
解説：
* VXLAN Traffic Verification:
* To ensure VXLAN traffic from the xe-0/0/12 interface is correctly encapsulated by the logical vtep.32770 and sent to a remote leaf device, it is essential to monitor the relevant interface statistics.
* The command show interfaces terse vtep.32770 statistics provides a concise overview of the traffic statistics for the specific VTEP interface, which can help verify whether traffic is being correctly encapsulated and transmitted.
* Explanation:
* This command is particularly useful for quickly checking the traffic counters and identifying any potential issues with VXLAN encapsulation or transmission.
* It allows you to confirm that traffic is flowing as expected, by checking the transmitted and received packet counters.
Data Center References:
* Monitoring interface statistics is a crucial step in troubleshooting and validating network traffic, particularly in complex overlay environments like EVPN-VXLAN.
質問 # 35
Exhibit.
The exhibit shows the truncated output of the show evpn database command.
Given this output, which two statements are correct about the host with MAC address 40:00:dc:01:00:04?
(Choose two.)
- A. The host is originating from irb.300.
- B. The host is assigned IP address 10.4.4.5.
- C. The host is originating from an ESI LAG.
- D. The host is located on VN110002.
正解：B、C
解説：
* Understanding the Output:
* The show evpn database command output shows the MAC address, VLAN, active source, timestamp, and IP address associated with various hosts in the EVPN instance.
* Analysis of the MAC Address:
* Option A:The MAC address 40:00:dc:01:00:04 is associated with the IP address 10.4.4.5, as indicated by the output in the IP address column. This confirms that this host has been assigned the IP 10.4.4.5.
* Option D:The active source for the MAC address 40:00:dc:01:00:04 is listed as 00:02:00:00:00:
04:00:04:00:00:04:00:04, which indicates that the host is connected via an ESI (Ethernet Segment Identifier) LAG (Link Aggregation Group). This setup is typicallyused in multi-homing scenarios to provide redundancy and load balancing across multiple physical links.
Conclusion:
* Option A:Correct-The host with MAC 40:00:dc:01:00:04 is assigned IP 10.4.4.5.
* Option D:Correct-The host is originating from an ESI LAG, as indicated by the active source value.
質問 # 36
Which statement is correct about a collapsed fabric EVPN-VXLAN architecture?
- A. It supports multiple vendors in the fabric as long as all the spine devices are Juniper devices deployed with L2 VTEPs
- B. Using Virtual Chassis at the leaf layer increases resiliency.
- C. Fully meshed back-to-back links are needed between the spine devices.
- D. Border gateway functions occur on border leaf devices.
正解：D
解説：
* Collapsed Fabric Architecture:
* A collapsed fabric refers to a simplified architecture where the spine and leaf roles are combined, often reducing the number of devices and links required.
* In this architecture, the spine typically handles core switching, while leaf switches handle both access and distribution roles.
* Understanding Border Gateway Functionality:
* Border gateway functions include connecting the data center to external networks or other data centers.
* In a collapsed fabric, these functions are usually handled at the leaf level, particularly on border leaf devices that manage the ingress and egress of traffic to and from the data center fabric.
* Correct Statement:
* D. Border gateway functions occur on border leaf devices:This is accurate in collapsed fabric architectures, where the border leaf devices take on the role of managing external connections and handling routes to other data centers or the internet.
Data Center References:
* The collapsed fabric model is advantageous in smaller deployments or scenarios where simplicity and cost-effectiveness are prioritized. It reduces complexity by consolidating functions into fewer devices, and the border leaf handles the critical task of interfacing with external networks.
In conclusion, border gateway functions are effectively managed at the leaf layer in collapsed fabric architectures, ensuring that the data center can communicate with external networks seamlessly.
質問 # 37
Which two statements are true about a pure IP fabric? (Choose two.)
- A. An IP fabric does not support Layer 2 protocols.
- B. Devices in an IP fabric function as Layer 3 routers.
- C. An IP fabric supports Layer 2 VLANs.
- D. Devices in an IP fabric must be connected to a fabric controller.
正解：A、B
解説：
* Understanding Pure IP Fabric:
* A pure IP fabric is a network design where all devices operate at Layer 3, meaning that each device in the fabric is a router that makes forwarding decisions based on IP addresses.
* Layer 2 Support:
* In a pure IP fabric, traditional Layer 2 protocols such as Spanning Tree Protocol (STP) or VLANs are not supported. Instead, the network relies entirely on Layer 3 routing protocols to manage traffic between devices.
* Routing Functionality:
* Since devices in an IP fabric operate as Layer 3 routers, they handle IP routing and provide network services based on IP addresses, not on MAC addresses or Layer 2 switching.
Conclusion:
* Option A:Correct-Devices in an IP fabric function as Layer 3 routers.
* Option D:Correct-A pure IP fabric does not support traditional Layer 2 protocols, making it a purely routed environment.
質問 # 38
Which two statements are correct about an IP fabric? (Choose two.)
- A. FBGP is only required to route mostrouting information to external devices outside the fabric.
- B. All leaf devices can use the same AS number in an IP fabric without making any adjustments to the EBGP configuration
- C. Only a single point to point EBGP session is required between peers in an IP fabric.
- D. The multipath multiple-as statement is required to enable ECMP if every device has a different AS number.
正解：B、D
解説：
* BGP in IP Fabric:
* In an IP fabric, Border Gateway Protocol (BGP) is used to manage the routing between leaf and spine devices. Each device can have the same or different Autonomous System (AS) numbers depending on the network design.
* Multipath Multiple-AS:
* Option B:If every device in the fabric has a different AS number, then enabling Equal-Cost Multi-Path (ECMP) routing requires the multipath multiple-as statement. This configuration allows BGP to consider multiple paths across different AS numbers as equal cost, enabling efficient load balancing across the network.
* Same AS Number Configuration:
* Option A:It's possible for all leaf devices to use the same AS number in an IP fabric, which simplifies the configuration. EBGP (External BGP) will still function correctly in this setup because BGP considers the peering relationship rather than strictly enforcing different AS numbers in this specific use case.
Conclusion:
* Option B:Correct-This statement is essential for enabling ECMP in a multi-AS environment.
* Option A:Correct-Leaf devices can share the same AS number without needing special EBGP configuration.
質問 # 39
Exhibit.
Referring to the configuration shown in the exhibit, assume that there is no external router present, and that the configuration is fabric-only.
Which two statements are true about the example configuration? (Choose two.)
- A. VNI 10006is assigned to vlan 800 (irb.800).
- B. Devices in irb.400 (vlan 400) are not able to communicate directly with devices in routing instance Customer A.
- C. Devices in routing instance Customer A are able to communicate with devices in routing instance Customer B
- D. Devices in irb.400 (vlan 400) and irb.800 (vlan 800) are able to communicate over the fabric.
正解：B、D
解説：
* Understanding the Configuration:
* The exhibit shows configurations for two VRFs (Customer_A and Customer_B) with specific VLANs and VNIs assigned. Each VRF has interfaces (IRBs) associated with particular VLANs.
* Communication Between VLANs and Routing Instances:
* Option B:VLAN 400 (irb.400) is part of Customer_B, and there is no direct connection or routing between Customer_A and Customer_B in the configuration provided. Therefore, devices in irb.400 cannot communicate directly with devices in the Customer_A routing instance.
* Option D:Since irb.400 (VLAN 400) and irb.800 (VLAN 800) are part of the same routing instance (Customer_B), they can communicate over the fabric using VXLAN encapsulation.
Conclusion:
* Option B:Correct-There is no direct communication between devices in irb.400 (Customer_B) and routing instance Customer_A.
* Option D:Correct-Devices in VLAN 400 and VLAN 800 can communicate within the Customer_B routing instance over the fabric.
質問 # 40
Exhibit.
Referring to the exhibit, why is the active source field blank for the entry that uses the 00:0c:29:e8:b7:39 MAC address?
- A. The EVPN route for this host does not have a valid next hop.
- B. This entry is associated with a multicast EVPN route.
- C. The ARP lookup for this host has failed.
- D. The host for this entry is locally connected to leaf1.
正解：A
解説：
In this scenario, the active source field is blank for the MAC address 00:0c:29:e8:b7:39, indicating an issue with how this MAC entry is being processed within the EVPN/VXLAN environment.
Step-by-Step Analysis:
* Understanding the MAC Entry:
* The active source field should normally indicate the source of the route advertisement for a specific MAC address within the EVPN. If it is blank, it suggests that there is a problem with how this entry is being learned or propagated.
* Possible Issues:
* Option A:If the EVPN route for this MAC address does not have a valid next hop, the entry might exist in the MAC table, but it will not have a valid path for forwarding, leading to a blank active source.
* Option B:If the ARP lookup had failed, the entry might not even appear in the MAC table.
However, the entry does exist, suggesting that ARP is not the primary issue here.
* Option C:If the host were locally connected, the active source should reflect a local interface, but the field is blank, ruling out local connection as the cause.
* Option D:Multicast EVPN routes typically do not appear in this manner in the MAC table, and this would not cause the active source to be blank.
Conclusion:The most logical explanation is that the EVPN route for this host exists but does not have a valid next hop, leading to the absence of an active source. This is consistent with how EVPN routing tables work in a VXLAN environment, where the lack of a valid next hop would prevent proper route advertisement and forwarding for the specific MAC address.
質問 # 41
You are deploying an IP fabric using EBGP and notice that your leaf devices are advertising and receiving all the routes. However, the routes are not installed in the routing table and are marked as hidden.
Which two statements describe how to solve the issue? (Choose two.)
- A. You need to configure multipath multiple-as.
- B. You need to configure loops 2.
- C. You need to configure a next-hop self policy.
- D. You need to configure as-override.
正解：A、B
質問 # 42
Which two statements are true about EVPN routes for Data Center Interconnect? (Choose two.)
- A. Type 5 EVPN routes require a VXLAN tunnel to the protocol next hop.
- B. Type 5 EVPN routes do not require a VXLAN tunnel to the protocol next hop.
- C. Type 2 EVPN routes do not require a VXLAN tunnel to the protocol next hop.
- D. Type 2 EVPN routes require a VXLAN tunnel to the protocol next hop.
正解：B、C
解説：
* Type 2 EVPN Routes:
* Type 2 routesadvertise MAC addresses within an EVPN instance and are used primarily for Layer 2 bridging. These routes do not require a VXLAN tunnel to the protocol next hop because they operate within the same Layer 2 domain.
* Type 5 EVPN Routes:
* Type 5 routesare used to advertise IP prefixes (Layer 3 routes) within EVPN. Similar to Type 2 routes, they do not require a VXLAN tunnel to the protocol next hop because they represent L3 routes, which are managed at the routing layer without the need for VXLAN encapsulation.
Conclusion:
* Option B:Correct-Type 2 routes do not need a VXLAN tunnel to the next hop, as they are used for Layer 2.
* Option D:Correct-Type 5 routes also do not need a VXLAN tunnel because they operate at Layer 3, handling IP prefixes.
質問 # 43
Exhibit.
You have implemented an EVPN-VXLAN data center. Device served must be able to communicate with device server2.
Referring to the exhibit, which two statements are correct? (Choose two.)
- A. An IRB interface must be configured on spinel and spine2.
- B. Traffic from server1 to server2 will transit a VXLAN tunnel to spinel or spine2. then a VXLAN tunnel from spinel or spine2 to Ieaf2.
- C. An IRB Interface must be configured on leaf1 and Ieaf2.
- D. Traffic from server! to server2 will transit the VXLAN tunnel between leaf1 and Ieaf2.
正解：C、D
解説：
* Understanding the Exhibit Setup:
* The network diagram shows an EVPN-VXLAN setup, a common design for modern data centers enabling Layer 2 and Layer 3 services over an IP fabric.
* Leaf1 and Leaf2 are the leaf switches connected to Server1 and Server2, respectively, with each server in a different subnet (172.16.1.0/24 and 172.16.2.0/24).
* Spine1 and Spine2 are part of the IP fabric, interconnecting the leaf switches.
* EVPN-VXLAN Basics:
* EVPN (Ethernet VPN) provides Layer 2 and Layer 3 VPN services using MP-BGP.
* VXLAN (Virtual Extensible LAN) encapsulates Layer 2 frames into Layer 3 packets for transmission across an IP network.
* VTEP (VXLAN Tunnel Endpoint) interfaces on leaf devices handle VXLAN encapsulation and decapsulation.
* Integrated Routing and Bridging (IRB):
* IRB interfaces are required on leaf1 and leaf2 (where the endpoints are directly connected) to route between different subnets (in this case, between 172.16.1.0/24 and 172.16.2.0/24).
* The IRB interfaces provide the necessary L3 gateway functions for inter-subnet communication.
* Traffic Flow Analysis:
* Traffic from Server1 (172.16.1.1) destined for Server2 (172.16.2.1) must traverse from leaf1 to leaf2.
* The traffic will be VXLAN encapsulated on leaf1, sent over the IP fabric, and decapsulated on leaf2.
* Since the communication is between different subnets, the IRB interfaces on leaf1 and leaf2 are crucial for routing the traffic correctly.
* Correct Statements:
* C. An IRB Interface must be configured on leaf1 and leaf2:This is necessary to perform the inter-subnet routing for traffic between Server1 and Server2.
* D. Traffic from server1 to server2 will transit the VXLAN tunnel between leaf1 and leaf2:
This describes the correct VXLAN operation where the traffic is encapsulated by leaf1 and decapsulated by leaf2.
Data Center References:
* In EVPN-VXLAN architectures, the leaf switches often handle both Layer 2 switching and Layer 3 routing via IRB interfaces. This allows for efficient routing within the data center fabric without the need to involve the spine switches for every routing decision.
* The described traffic flow aligns with standard EVPN-VXLAN designs, where direct VXLAN tunnels between leaf switches enable seamless and scalable communication across a data center network.
質問 # 44
Exhibit.
A VXLAN tunnel has been created between leaf1and Ieaf2 in your data center. Referring to the exhibit, which statement is correct?
- A. Traffic sent from server1to server2 will be dropped on Ieaf2.
- B. Traffic sent from server1to server2 will be tagged with VLAN ID 100 on Ieaf2 and forwarded to server2.
- C. Traffic sent from server1to server2 will be tagged with VLAN ID 200 on Ieaf2 and forwarded to server2.
- D. Traffic sent from server1to server2 will be dropped on leaf1.
正解：C
解説：
* Understanding VXLAN Tunneling:
* VXLAN (Virtual Extensible LAN) is a network virtualization technology that addresses the scalability issues associated with traditional VLANs. VXLAN encapsulates Ethernet frames in UDP, allowing Layer 2 connectivity to extend across Layer 3 networks.
* Each VXLAN network is identified by a unique VXLAN Network Identifier (VNI). In this exhibit, we have two VNIs, 5100 and 5200, assigned to the VXLAN tunnels between leaf1 and leaf2.
* Network Setup Details:
* Leaf1:Connected to Server1 with VLAN ID 100 and associated with VNI 5100.
* Leaf2:Connected to Server2 with VLAN ID 200 and associated with VNI 5200.
* Spine:Acts as the interconnect between leaf switches.
* Traffic Flow Analysis:
* When traffic is sent from Server1 to Server2, it is initially tagged with VLAN ID 100 on leaf1.
* The traffic is encapsulated into a VXLAN packet with VNI 5100 on leaf1.
* The packet is then sent across the network (via the spine) to leaf2.
* On leaf2, the VXLAN header is removed, and the original Ethernet frame is decapsulated.
* Leaf2 will then associate this traffic with VLAN ID 200 before forwarding it to Server2.
* Correct Interpretation of the Exhibit:
* The traffic originating from Server1, which is tagged with VLAN ID 100, will be encapsulated into VXLAN and transmitted to leaf2.
* Upon arrival at leaf2, it will be decapsulated, and since it is associated with VNI 5200 on leaf2, the traffic will be retagged with VLAN ID 200.
* Therefore, the traffic will reach Server2 tagged with VLAN ID 200, which matches the network configuration shown in the exhibit.
* Data Center References:
* This configuration is typical in data centers using VXLAN for network virtualization. It allows isolated Layer 2 segments (VLANs) to be stretched across Layer 3 boundaries while maintaining distinct VLAN IDs at each site.
* This approach is efficient for scaling large data center networks while avoiding VLAN ID exhaustion and enabling easier segmentation.
In summary, the correct behavior, as per the exhibit and the detailed explanation, is that traffic sent from Server1 will be tagged with VLAN ID 200 when it reaches Server2 via leaf2. This ensures proper traffic segmentation and handling across the VXLAN-enabled data center network.
質問 # 45
You are adding a server lo a tenant's network within your data center and must limit access to a specific traffic type within the tenant network without pushing all tenant traffic through a firewall.
What will satisfy this requirement?
- A. Use a static route in the tenant VRF with a firewall as the next hop for traffic to the new server.
- B. Use filter-based forwarding.
- C. Put the new server on a unique subnet within the tenant's network.
- D. Use route leaking with EVPN and a routing policy.
正解：B
解説：
* Controlling Traffic Within a Tenant's Network:
* The requirement is to limit access to specific traffic types within a tenant's network without routing all tenant traffic through a firewall. This requires a selective method that can direct specific types of traffic to different paths based on the nature of the traffic.
* Filter-Based Forwarding (FBF):
* FBF is a technique that allows for routing decisions based on filters applied to the traffic, such as matching on source IP addresses, destination IP addresses, or even specific application types (like HTTP or FTP). This allows specific types of traffic to be forwardedto a specific next hop (e.g., a firewall) without affecting the entire traffic flow within the tenant's network.
Conclusion:
* Option B:Correct-Filter-based forwarding allows for granular control of traffic, ensuring that only specific types of traffic within the tenant's network are redirected through a firewall, satisfying the requirement.
質問 # 46
Exhibit.
You are troubleshooting an IP fabric (or your data center. You notice that your traffic is not being load balanced to your spine devices from your leaf devices. Referring to the configuration shown in the exhibit, what must be configured to solve this issue?
- A. The load-balance policy must be applied to the forwarding table under the routing-options hierarchy.
- B. The multipastmultiple -as configuration must be configured for each peer in the BGP spine group.
- C. The load-balance policy must be applied as an export policy to your BGP
- D. The load-balance policy must have a from statement that matches on protocol bgp.
正解：B
解説：
* IP Fabric Load Balancing:
* In the provided configuration, traffic is not being load-balanced to the spine devices. The issue likely relates to how BGP routes are being selected and whether Equal-Cost Multi-Path (ECMP) is functioning correctly.
* Multipath Multiple-AS:
* Option B:The multipath multiple-as configuration is essential when using BGP in an IP fabric where devices belong to different Autonomous Systems (AS). This setting allows BGP to consider multiple paths (even across different AS numbers) as equal cost, enabling ECMP and proper load balancing across spine devices.
Conclusion:
* Option B:Correct-The multipath multiple-as configuration is necessary for achieving ECMP and effective load balancing in a multi-AS BGP environment.
質問 # 47
You are designing an IP fabric tor a large data center, and you are concerned about growth and scalability.
Which two actions would you take to address these concerns? (Choose two.)
- A. Use EX4300 Series devices as the spine devices.
- B. Use OFX5700 Series devices as the super spines.
- C. Design a five-stage Clos IP fabric.
- D. Design a three-stage Clos IP fabric.
正解：B、D
解説：
* Clos IP Fabric Design:
* A Clos fabric is a network topology designed for scalable, high-performance data centers. It is typically arranged in multiple stages, providing redundancy, high bandwidth, and low latency.
* Three-Stage Clos Fabric:
* Option B:A three-stage Clos fabric, consisting of leaf, spine, and super spine layers, is widely used in data centers. This design scales well and allows for easy expansion by adding more leaf and spine devices as needed.
* Super Spines for Scalability:
* Option D:Using high-capacity devices like the QFX5700 Series as super spines can handle the increased traffic demands in large data centers and support future growth. These devices provide the necessary bandwidth and scalability for large-scale deployments.
Conclusion:
* Option B:Correct-A three-stage Clos fabric is a proven design that addresses growth and scalability concerns in large data centers.
* Option D:Correct-QFX5700 Series devices are suitable for use as super spines in large-scale environments due to their high performance.
質問 # 48
Which two statements are true about IP fabrics using unnumbered BGP? (Choose two.)
- A. Unnumbered BGP peering automatically provisions IPv4 peering.
- B. Unnumbered BGP requires that family inet6 is configured on each interface.
- C. Unnumbered BGP requires that family inet is configured on each interface.
- D. Unnumbered BGP peering automatically provisions IPv6 peering.
正解：A、B
解説：
https://www.juniper.net/documentation/us/en/software/nce/nce-225-bgp-unnumbered/index.html
質問 # 49
You are asked for TX and RX traffic statistics for each interface to which an application server is attached.
The statistics need to be reported every five seconds. Using the Junos default settings, which telemetry method would accomplish this request?
- A. gNMI
- B. Native Sensors
- C. OpenConfig
- D. SNMP
正解：B
解説：
* Telemetry Methods in Junos:
* Telemetry is used to collect and report data from network devices. For high-frequency statistics reporting, such as every five seconds, you need a telemetry method that supports this level of granularity and real-time monitoring.
* Junos Native Sensors:
* Option C:Native Sensors in Junos provide detailed, high-frequency telemetry data, including TX and RX traffic statistics for interfaces. They are designed to offer real-time monitoring with customizable sampling intervals, making them ideal for the five-second reporting requirement.
Conclusion:
* Option C:Correct-Native Sensors in Junos are capable of providing the required high-frequency telemetry data every five seconds.
質問 # 50
Exhibit.
The exhibit shows the truncated output of the show evpn database command.
Given this output, which two statements are correct about the host with MAC address 40:00:dc:01:00:04?
(Choose two.)
- A. The host is originating from irb.300.
- B. The host is assigned IP address 10.4.4.5.
- C. The host is originating from an ESI LAG.
- D. The host is located on VN110002.
正解：B、C
解説：
* Understanding the Output:
* The show evpn database command output shows the MAC address, VLAN, active source, timestamp, and IP address associated with various hosts in the EVPN instance.
* Analysis of the MAC Address:
* Option A:The MAC address 40:00:dc:01:00:04 is associated with the IP address 10.4.4.5, as indicated by the output in the IP address column. This confirms that this host has been assigned the IP 10.4.4.5.
* Option D:The active source for the MAC address 40:00:dc:01:00:04 is listed as 00:02:00:00:00:
04:00:04:00:00:04:00:04, which indicates that the host is connected via an ESI (Ethernet Segment Identifier) LAG (Link Aggregation Group). This setup is typicallyused in multi-homing scenarios to provide redundancy and load balancing across multiple physical links.
Conclusion:
* Option A:Correct-The host with MAC 40:00:dc:01:00:04 is assigned IP 10.4.4.5.
* Option D:Correct-The host is originating from an ESI LAG, as indicated by the active source value.
質問 # 51
......
Juniper JN0-683 認定試験の出題範囲：
| トピック | 出題範囲 |
|---|---|
| トピック 1 |
|
| トピック 2 |
|
| トピック 3 |
|
JN0-683問題集はJNCIP-DC認証済み試験問題と解答：https://www.passtest.jp/Juniper/JN0-683-shiken.html
JN0-683無料試験学習ガイド！（更新された68問あります)：https://drive.google.com/open?id=1Yo_BHqQ5GBwb5Zcgf9MghUNax0hSm0Bl
